TITAN Post Pallet M2 Base
This heavy duty stacking post pallet is quite simply brilliant value for money! Our TITAN post pallets are made in Europe and load tested & certified.
This post pallet base can have post pallet stacking poles inserted in each corner to build the post pallets up into a tower. The height of the poles can be changed to suit your products or application. The use of post pallets can negate the need for pallet racks and pallet racking, especially for warehouse temporary racking or peak periods. Hoops are fitted to the underside of the post pallet for forklifts to safely pick up the post pallet.
The price is for the base only - posts are extra. The posts come in a selection of post lengths available as options.
The post pallet stacking frames are made from prime quality steel and galvanized for a long and hard wearing life. Each pallet base is rated to 2000kg, and they can be stacked 4 high with a total load of 8 tonnes with 1.6m posts!
These have been load tested by TÜV Rheinland. The European manufacturing standards ensures that the quality of the welding is far superior to Far Eastern imports.
Titan Post Pallet Stillages Buy Online Now
| Base Frame |
1060 x 1875mm |
| External Dims of Corner Sockets |
1070 x 1920mm |
| Internal Dims of Corner Sockets |
935 x 1785mm |
| Load Capacity |
2000kg |
| Stacking |
4 High |
| Internal Dims of Fork Lift Guards |
80 x 200mm |
| Fork Lift Guards - Centres |
835 |
| Weight of M2 base |
47kg |
| Weight of 1.2m post |
6kg each |
| Weight of 1.5m post |
7.5kg each |
| Weight of 1.8m post |
9kg each |
TITAN Post Pallets Undergoing Load Rating Test
Photographs of TITAN Post Pallet load tests carried out in Building Research Institute in Katowice. M1 post pallet in photographs, stacked 5 high, are loaded with 9500 kg. Estimated max. typical load for such post pallet stack is 7500 kg.
